Ultra light Portable Square Facing machine for tubes. Precision facing (min scale of 0.05mm accuracy) with little/no vibration operation.
- Using a rechargeable motor(Ultra-light)
- Light and no vibration
- Precise facing(minimum scale is 0.05mm)
- Providing the vertical and precise processing surface(no burr)
- High-capacity battery equipped(S-EM1.0)
- Brush Less motor equipped (S-EM1.0)
- Tool designed for easy tip-out
- Usage of Insert tip
Enable you to use 4 surfaces (Titanium coating) / Long-lived and high strength insert tip
| Machine Specifications | ||
|---|---|---|
| Model | Specification | |
| S-EM0.5 | Rating | 10.8V, 2Ah |
| Speed | 0 – 400RPM | |
| Capacity | 1/4, 3/8, 1/2inch (6.35, 9.53, 12.7mm) | |
| Weight | 1.25kg(including battery) | |
| S-EM1.0 | Rating | 18V, 5Ah |
| Speed | 0 – 500RPM | |
| Capacity | 1/4,3/8,1/2,3/4, 1inch (6.35, 9.53, 12.7, 19.5, 25.44mm) | |
| Weight | 2.3kg(including battery) | |
| Insert Tip Specification | ||
|---|---|---|
| Insert Tip | Model | |
| S-EM05_0811 | S-EM0.5 | |
| S-EM10_1412 | S-EM1.0 | |
